Loader Performance
- Tipping Load Straight with Bucket: 2994 lbs (1358 kg)
- Rated Operating Capacity (ROC)
- Straight with Bucket: 1497 lbs (679 kg)
- Articulated with Bucket: 1447 lbs (656 kg)
- Tipping Load with Optional 500# Counterweight
- Straight with Counterweight: 4015 lbs (1824 kg)
- ROC with Counterweight
- Straight with Bucket & Counterweight: 2007 lbs (910 kg)
- Articulated with Bucket & Counterweight: 1882 lbs (853 kg)
- Lifting Capacity at Ground Level (with Operator): 2584 lbs (1172 kg)
- Breakout Force – Bucket Rollback: 3484 lbs (1580 kg)
- Lifting Capacity to 65″: 1600 lbs (726 kg)
- Loader Raise/Lower Time: 3.0 sec / 3.0 sec
Size and Speed
- Operating Weight with Bucket: 3790 lbs (1719 kg)
- With Optional Counterweight: 4295 lbs (1948 kg)
- Length Without Attachment: 89.4” (2271 mm)
- Height Without Beacon: 72.4” (1839 mm)
- With Beacon: 75.4” (1915 mm)
- Travel Speed with Standard 26 X 12.00-12 ATW-020 Tires: 8.0 mph (13.5 kph)
- Width with Standard Tire: 57.7” (1466 mm)
Features
- Low Profile Universal Quick Attach: Standard
- Conversion to Standard Quick Attach: Standard
- Automatic Parking Brake: Standard
- Road Lights & LED Worklights: Standard
- Multi-Function Capable Joystick: Standard
- Magnetic Pump Clutches for Easy Starting: Standard
- Convenient Engine Serviceability: Standard
- Forward & Reverse Foot Pedal Control: Standard
- Electric Differential Lock: Optional
- Enclosure Windows & Door: Optional
- Cab Heater: Optional
- Front & Rear Remote Hydraulic Outlets: Optional
- 500# Easy Change Rear Ballast Package: Optional
Safety Equipment
- Operator Interlock Control System: Standard
- Lap Bar & Seat Presence Switch: Standard
- Individual Drive Presence Switch(es): Standard
- Loader Arm Safety Stop: Standard
- Backup Alarm & Rotating Beacon: Standard
- Fully Retractable Seat Belt: Standard
- ROPS/FOPS Certified: Standard
Engine
- Horsepower: 38 Gross / 35 Net
- Displacement: 997 cc
- Engine Type: Gasoline, Kohler EFI
- Cooling: Air Cooled
- Fuel Tank Capacity: 9.3 gal (35.2 L)
Auxiliary Hydraulic System (Optional)
- Hydraulic Flow: 19 GPM (72 LPM)
- System Relief at Quick Couplers: 2900 psi
- Quick Change Filter: Standard
